Fill-Rite Fuel Transfer Pump with Meter & Nozzle, 75 LPM FR701VGL

Model:: FR701VGL
Category:: Water Pumps › Electric Water Pumps

✓Delivery across Saudi Arabia
✓Bulk and project orders
✓One quotation for your full list
✓Tax invoice (VAT) with every order

Request a quote for this item

Prices are quoted per order — they depend on quantity, delivery city and current stock.

Technical specifications

Model	FR701VGL
Brand	Fill-Rite
Type	Fuel Transfer Pump with Meter & Nozzle
Power Source	Electrical
Power Type	230V AC
AC Frequency (Hz)	60 Hz
Motor Power (HP)	0.33 HP (1/3 HP)
Max Current (A)	2.4 A
Max Flowrate	20 GPM / 75 LPM
Duty Cycle (min)	30 min ON / 30 min OFF
Compatible Fluids	Diesel, Kerosene, Biodiesel (up to B20), Gasoline (up to E15), Mineral Spirits, Heptane.
Inlet Size / Connection	1.25" / Female / NPT
Outlet Size / Connection	0.75" / Female / NPT
Mounting Size / Thread	2" / NPT / Bung Mount
Thermal Protection Switch	Yes
Self-Priming	Yes
Suction Lift (ft.)	15 ft
Dry Vacuum (in. Hg)	12 in. Hg
Discharge Head (ft)	53 ft
Max Discharge Pressure (PSI)	23 PSI
Strainer Mesh Size (Micron)	40 x 40 x .010"
Viscosity Range (cSt)	0.5 - 5.5 cSt
Operating Temperature Range (°F)	-13°F to 150°F (-25°C to 65.5°C)
Meter Display Type	Mechanical
Meter Display Digits	3
Meter Accuracy	+/- 1%
Meter Repeatability	+/- 0.38%
Dimensions (D x W x H)	Approx. 296.5 × 359.4 × 421.6 mm
Net Weight	Approx. 27 Kg
Country of Origin	USA

About this product

Fill-Rite Fuel Transfer Pump with Meter & Nozzle, 75 LPM FR701VGL is available to order through BRO Global for contractors, factories, workshops, facilities teams and project sites across Saudi Arabia.

It is a Fill-Rite product, made in USA, supplied with its standard accessories and documentation as issued by the manufacturer.

Send us the quantity, delivery city and required date — our procurement team replies with price, availability and lead time, and can combine it with the rest of your order on one quotation.
